Specifications
XLf 16155 A Specification
Subwoofer
- Speaker Size : 6.5″ (165mm)
- Cone Composition : Aluminum
- Magnet Type : Ferrite
- Enclosure Housing Material : Die-cast Aluminum
- Enclosure Dimension (LxWxH) : 205x170x70mm
- Enclosure Net Weight : 2.75kg
Amplifier
- Amplifier Technology : Class D
- Normal Output Power (RMS) : 150W
- Max. Power Output : 300W
- Sensitivity (In Car/1W) : >95dB
- Signal / Noise Ratio (dB) : >95dB
- Impedance : 0.4 ohms
- Frequency Response : 25Hz-150Hz
- Low Pass Filter : 40Hz-160Hz
- Voltage : 14.4V (10V-16V)
- Phase Switch : 0 deg / 180 deg
- Automatic On/Off : High Level Input Only
- Audio in Sensitivity : Speaker Input (140mV-5.4V)/ RCA Input (280mV-10.8V)
Accessories
- Remote Controller : 4.5m Wired Remote
- 2 x Screws : M5x10mm
- 2 x Screws : M4x20mm
- 2 x Mounting Brackets : 45 x 22 x 6mm
- 1 x 4 Pin Low Level Wiring Harness
